Renesas Electronics America Inc-PS9031-Y-F3-AX - Isolators - Gate Drivers Product Specifications and Latest Quotes

Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	5000Vrms
Common Mode Transient Immunity (Min):	50kV/µs
Propagation Delay tpLH / tpHL (Max):	175ns, 175ns
Pulse Width Distortion (Max):	75ns
Rise / Fall Time (Typ):	40ns, 40ns
Current - Output High, Low:	2A, 2A
Current - Peak Output:	2.5A
Voltage - Forward (Vf) (Typ):	1.56V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	15V ~ 30V
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.295", 7.50mm Width), 5 Leads
Supplier Device Package:	5-SOP
Approval Agency:	CSA, UL

Renesas Electronics America Inc PS9031-Y-F3-AX
