Please send RFQ , we will respond immediately.
| Part Number | ISL9110IRTNZ-T7A | ISL9112IRTNZ-T7A | ISL91107IRTNZ-T7A | ISL9110IRT7Z-T7A | ISL9110IRTAZ-T7A |
|---|---|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc |
| Product Status | Active | Active | Active | Active | Active |
| Function | Step-Up/Step-Down | Step-Up/Step-Down | Step-Up/Step-Down | Step-Up/Step-Down | - |
| Output Configuration | Positive | Positive | Positive | Positive | - |
| Topology | Buck-Boost | Buck-Boost | Buck-Boost | Buck-Boost | - |
| Output Type | Fixed | Fixed | Fixed | Fixed | - |
| Number of Outputs | 1 | 1 | 1 | 1 | - |
| Voltage - Input (Min) | 1.8V | 1.8V | 1.8V | 1.8V | - |
| Voltage - Input (Max) | 5.5V | 5.5V | 5.5V | 5.5V | - |
| Voltage - Output (Min/Fixed) | 3.3V | 3.3V | 3.3V | 5V | - |
| Voltage - Output (Max) | - | - | - | - | - |
| Current - Output | 1.2A | 1.2A | 2A | 1.2A | - |
| Frequency - Switching | 2.5MHz | 2.5MHz | 2.5MHz | 2.5MHz | - |
| Synchronous Rectifier | Yes | Yes | Yes | Yes | - |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 12-WFDFN Exposed Pad | 12-WFDFN Exposed Pad | 20-WFQFN Exposed Pad | 12-WFDFN Exposed Pad | 12-WFDFN Exposed Pad |
| Supplier Device Package | 12-TDFN (3x3) | 12-TDFN (3x3) | 20-TQFN (3x4) | 12-TDFN (3x3) | 12-TDFN (3x3) |
