| Part Number | HA1-5320-5 | HA1-5340-5 | HA1-5330-5 | HA1-5320-8 | HA1-5320-2 |
|---|---|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Harris Corporation | Intersil | Harris Corporation | Renesas Electronics America Inc |
| Product Status | Obsolete | Active | Active | Active | Obsolete |
| Amplifier Type | Sample and Hold | Sample and Hold | Sample and Hold | Sample and Hold | Sample and Hold |
| Number of Circuits | 1 | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - | - |
| Slew Rate | 45V/µs | 60V/µs | 90V/µs | - | 45V/µs |
| Gain Bandwidth Product | 2 MHz | 10 MHz | 4.5 MHz | - | 2 MHz |
| -3db Bandwidth | - | - | - | - | - |
| Current - Input Bias | 100 nA | 70 nA | 20 nA | - | 70 nA |
| Voltage - Input Offset | 500 µV | 1.5 mV | 200 µV | - | 200 µV |
| Current - Supply | 11mA | 19mA | 19mA | - | 11mA |
| Current - Output / Channel | 10 mA | 10 mA | 10 mA | - | 10 mA |
| Voltage - Supply Span (Min) | 27 V | 24 V | 20 V | 27 V | 27 V |
| Voltage - Supply Span (Max) | 40 V | 36 V | 40 V | 40 V | 40 V |
| Operating Temperature | 0°C ~ 75°C | 0°C ~ 75°C | 0°C ~ 75°C | - | -55°C ~ 125°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) | 14-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 14-CERDIP | 14-CERDIP | 14-CERDIP | 14-CERDIP | 14-CERDIP |
