| Part Number | EL5411IRE-T13 | EL5411IREZ-T13 | EL5411IRZ-T13 | EL5412IRE-T13 | EL5411IR-T13 |
|---|---|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Amplifier Type | Voltage Feedback | Voltage Feedback | Voltage Feedback | Voltage Feedback | Voltage Feedback |
| Number of Circuits | 4 | 4 | 4 | 4 | 4 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 75V/µs | 75V/µs | 75V/µs | 55V/µs | 75V/µs |
| Gain Bandwidth Product | 32 MHz | 32 MHz | 32 MHz | 22 MHz | 32 MHz |
| -3db Bandwidth | 60 MHz | 60 MHz | 60 MHz | 40 MHz | 60 MHz |
| Current - Input Bias | 2 nA | 2 nA | 2 nA | 2 nA | 2 nA |
| Voltage - Input Offset | 3 mV | 3 mV | 3 mV | 3 mV | 3 mV |
| Current - Supply | 10mA (x4 Channels) | 10mA (x4 Channels) | 10mA (x4 Channels) | 2.5mA (x4 Channels) | 10mA (x4 Channels) |
| Current - Output / Channel | 65 mA | 65 mA | 65 mA | 65 mA | 65 mA |
| Voltage - Supply Span (Min) | 4.5 V | 4.5 V | 4.5 V | 4.5 V | 4.5 V |
| Voltage - Supply Span (Max) | 16.5 V | 16.5 V | 16.5 V | 16.5 V | 16.5 V |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) Exposed Pad | 14-TSSOP (0.173", 4.40mm Width) Exposed Pad | 14-TSSOP (0.173", 4.40mm Width) Exposed Pad | 14-TSSOP (0.173", 4.40mm Width) Exposed Pad | 14-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 14-HTSSOP | 14-HTSSOP | 14-HTSSOP | 14-HTSSOP | 14-HTSSOP |
