| Part Number | CA3083 | CA3083M | CA3083Z |
|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Intersil | Renesas Electronics America Inc |
| Product Status | Obsolete | Active | Obsolete |
| Transistor Type | 5 NPN | - | 5 NPN |
| Current - Collector (Ic) (Max) | 100mA | - | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 15V | - | 15V |
| Vce Saturation (Max) @ Ib, Ic | 700mV @ 5mA, 50mA | - | 700mV @ 5mA, 50mA |
| Current - Collector Cutoff (Max) | 10µA | - | 10µA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 50mA, 3V | - | 40 @ 50mA, 3V |
| Power - Max | 500mW | - | 500mW |
| Frequency - Transition | 450MHz | - | 450MHz |
| Operating Temperature | 150°C (TJ) | - | 150°C (TJ) |
| Mounting Type | Through Hole | - | Through Hole |
| Package / Case | 16-DIP (0.300", 7.62mm) | - | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-PDIP | - | 16-PDIP |
