| Part Number | 2SC5754-T2-A | 2SC5751-T2-A | 2SC5753-T2-A |
|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Renesas Electronics America Inc | CEL |
| Product Status | Active | Obsolete | Obsolete |
| Transistor Type | NPN | NPN | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 5V | 6V | 6V |
| Frequency - Transition | 20GHz | 15GHz | 12GHz |
| Noise Figure (dB Typ @ f) | - | 1.7dB @ 2GHz | 1.7dB @ 2GHz |
| Gain | 6.5dB | 16dB | 13.5dB |
| Power - Max | 735mW | 205mW | 205mW |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 100mA, 3V | 75 @ 20mA, 3V | 75 @ 30mA, 3V |
| Current - Collector (Ic) (Max) | 500mA | 50mA | 100mA |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOT-343F | SOT-343F | SOT-343F |
| Supplier Device Package | SOT-343F | SOT-343F | SOT-343F |
