| Part Number | UC3843ADX | UC3843DX | UC3842ADX | UC3843AD | UC3843AD1 | UC3843AD2 | UC3843AD8 | UC3843ADM |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | onsemi | Fairchild Semiconductor | Texas Instruments | STMicroelectronics | onsemi | Texas Instruments | Microsemi Corporation |
| Product Status | Active | Obsolete | Obsolete | Active | Obsolete | Active | Active | Discontinued at Digi-Key |
| Output Type | - | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver |
| Function | - | Step-Up, Step-Up/Step-Down | Step-Up, Step-Down, Step-Up/Step-Down | Step-Up, Step-Down, Step-Up/Step-Down | Step-Up, Step-Up/Step-Down | Step-Up, Step-Up/Step-Down | Step-Up, Step-Down, Step-Up/Step-Down | Step-Up, Step-Down |
| Output Configuration | - | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable |
| Topology | - | Boost, Flyback | Boost, Buck, Flyback, Forward | Boost, Buck, Flyback, Forward | Boost, Flyback | Boost, Buck, Flyback, Forward | Boost, Buck, Flyback, Forward | Boost, Buck, Flyback, Forward |
| Number of Outputs | - | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Output Phases | - | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Voltage - Supply (Vcc/Vdd) | - | 7.6V ~ 30V | 10V ~ 30V | 7.6V ~ 30V | 10V ~ 30V | 7.6V ~ 30V | 7.6V ~ 30V | 7.6V ~ 30V |
| Frequency - Switching | - | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz |
| Duty Cycle (Max) | - | 97% | 96% | 96% | 96% | 96% | 96% | 96% |
| Synchronous Rectifier | - | No | No | No | No | No | No | No |
| Clock Sync | - | No | No | No | No | No | No | No |
| Serial Interfaces | - | - | - | - | - | - | - | - |
| Control Features | - | Frequency Control | Frequency Control | Frequency Control | Frequency Control | Frequency Control | Frequency Control | Frequency Control |
| Operating Temperature | - | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | -40°C ~ 150°C (TJ) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) |
| Mounting Type | - | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | - | 14-SOIC (0.209", 5.30mm Width) | 8-SOIC (0.154", 3.90mm Width) | 14-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | - | 14-SOP | 8-SOIC | 14-SOIC | 8-SOIC | 8-SOIC | 8-SOIC | 8-SOIC |
