| Part Number | QTLP670CIBTR | QTLP610CIBTR | QTLP670CBTR |
|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | Everlight Electronics Co Ltd | Fairchild Semiconductor |
| Product Status | Active | Active | Active |
| Color | Blue | Blue | Blue |
| Configuration | - | Standard | Standard |
| Lens Color | Colorless | Colorless | Colorless |
| Lens Transparency | Clear | Clear | Clear |
| Millicandela Rating | 60mcd | 30mcd | 30mcd |
| Lens Style | Round with Flat Top | Rectangle with Domed Top | Round with Flat Top |
| Lens Size | 2.40mm Dia | 2.00mm x 1.00mm | 2.40mm Dia |
| Voltage - Forward (Vf) (Typ) | 3.5V | 3.5V | 3.8V |
| Current - Test | 20mA | 20mA | 20mA |
| Viewing Angle | 120° | 120° | 120° |
| Mounting Type | Surface Mount | Surface Mount, Right Angle | Surface Mount |
| Wavelength - Dominant | 470nm | 470nm | 465nm |
| Wavelength - Peak | 465nm | 465nm | 430nm |
| Features | - | - | - |
| Package / Case | 2-PLCC | 2-SMD, No Lead | 2-PLCC |
| Supplier Device Package | 2-PLCC | SMD | 2-PLCC |
| Size / Dimension | 3.10mm L x 2.80mm W | 3.00mm L x 2.00mm W | 3.20mm L x 2.80mm W |
| Height (Max) | 2.10mm | 1.10mm | 2.10mm |
