| Part Number | QTLP670CETR | QTLP630CETR | QTLP670C2TR | QTLP670C4TR | QTLP670C7TR | QTLP670CBTR |
|---|---|---|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | Everlight Electronics Co Ltd | Everlight Electronics Co Ltd | Everlight Electronics Co Ltd | Everlight Electronics Co Ltd | Fairchild Semiconductor |
| Product Status | Obsolete | Active | Active | Active | Active | Active |
| Color | Orange | Orange | Red | Green | Red | Blue |
| Configuration | Standard | Standard | Standard | Standard | Standard | Standard |
| Lens Color | Colorless | Colorless | Colorless | Colorless | Colorless | Colorless |
| Lens Transparency | Clear | Clear | Clear | Clear | Clear | Clear |
| Millicandela Rating | 65mcd | 40mcd | 10mcd | 25mcd | 40mcd | 30mcd |
| Lens Style | Round with Flat Top | Rectangle with Flat Top | Round with Flat Top | Round with Flat Top | Round with Flat Top | Round with Flat Top |
| Lens Size | 2.40mm Dia | 1.40mm x 1.25mm | 2.40mm Dia | 2.40mm Dia | 2.40mm Dia | 2.40mm Dia |
| Voltage - Forward (Vf) (Typ) | 2V | 2V | 2V | 2.1V | 1.9V | 3.8V |
| Current - Test | 20mA | 20mA | 20mA | 20mA | 20mA | 20mA |
| Viewing Angle | 120° | 140° | 120° | 120° | 120° | 120° |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Wavelength - Dominant | 615nm | 615nm | 630nm | 570nm | 645nm | 465nm |
| Wavelength - Peak | 620nm | 620nm | 635nm | 565nm | 660nm | 430nm |
| Features | - | - | - | - | - | - |
| Package / Case | 2-PLCC | 0805 (2012 Metric) | 2-PLCC | 2-PLCC | 2-PLCC | 2-PLCC |
| Supplier Device Package | 2-PLCC | 0805 | 2-PLCC | 2-PLCC | 2-PLCC | 2-PLCC |
| Size / Dimension | 3.20mm L x 2.80mm W | 2.00mm L x 1.25mm W | 3.20mm L x 2.80mm W | 3.20mm L x 2.80mm W | 3.20mm L x 2.80mm W | 3.20mm L x 2.80mm W |
| Height (Max) | 2.10mm | 1.20mm | 2.10mm | 2.10mm | 2.10mm | 2.10mm |
