| Part Number | MV64520 | MV64530 | MV64521 |
|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | Everlight Electronics Co Ltd | Everlight Electronics Co Ltd |
| Product Status | Active | Active | Active |
| Color | Green | Green | Green |
| Configuration | - | Standard | Standard |
| Lens Color | Green | Green | Green |
| Lens Transparency | Clear | Diffused | Clear |
| Millicandela Rating | 25mcd | 20mcd | 100mcd |
| Lens Style | Round with Domed Top | Round with Domed Top | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 | 5mm, T-1 3/4 | 5mm, T-1 3/4 |
| Voltage - Forward (Vf) (Typ) | 2.2V | 2.2V | 2.2V |
| Current - Test | 20mA | 20mA | 20mA |
| Viewing Angle | 35° | 75° | 35° |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Wavelength - Dominant | - | - | - |
| Wavelength - Peak | 562nm | 562nm | 562nm |
| Features | - | - | - |
| Package / Case | Radial | Radial | Radial |
| Supplier Device Package | T-1 3/4 | T-1 3/4 | T-1 3/4 |
| Size / Dimension | - | - | - |
| Height (Max) | 8.89mm | 8.89mm | 8.89mm |
