| Part Number | MM74HC14J | MM74HC14SJ | MM74HC14M | MM74HC14N | MM74HC10J | MM74HC11J |
|---|---|---|---|---|---|---|
| Manufacturer | National Semiconductor | Fairchild Semiconductor | onsemi | onsemi | National Semiconductor | National Semiconductor |
| Product Status | Active | Obsolete | Active | Obsolete | Active | Active |
| Logic Type | Inverter | Inverter | Inverter | Inverter | NAND Gate | - |
| Number of Circuits | 6 | 6 | 6 | 6 | 3 | - |
| Number of Inputs | 1 | 1 | 1 | 1 | 3 | - |
| Features | Schmitt Trigger | Schmitt Trigger | Schmitt Trigger | Schmitt Trigger | - | - |
| Voltage - Supply | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V | 2V ~ 6V | - |
| Current - Quiescent (Max) | 2 µA | 2 µA | 2 µA | 2 µA | 1 µA | - |
| Current - Output High, Low | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 5.2mA, 5.2mA | - |
| Logic Level - Low | 0.3V ~ 1.2V | 0.3V ~ 1.2V | 0.3V ~ 1.2V | 0.3V ~ 1.2V | 0.5V ~ 1.8V | - |
| Logic Level - High | 1.5V ~ 4.2V | 1.5V ~ 4.2V | 1.5V ~ 4.2V | 1.5V ~ 4.2V | 1.5V ~ 4.2V | - |
| Max Propagation Delay @ V, Max CL | 21ns @ 6V, 50pF | 21ns @ 6V, 50pF | 21ns @ 6V, 50pF | 21ns @ 6V, 50pF | 16ns @ 6V, 50pF | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | - |
| Mounting Type | Through Hole | Surface Mount | Surface Mount | Through Hole | - | - |
| Supplier Device Package | 14-DIP | 14-SOP | 14-SOIC | 14-MDIP | - | - |
| Package / Case | 14-DIP (0.300", 7.62mm) | 14-SOIC (0.209", 5.30mm Width) | 14-SOIC (0.154", 3.90mm Width) | 14-DIP (0.300", 7.62mm) | - | - |
