| Part Number | LM317LIBP | LM317LILP | LM317LIBPX |
|---|---|---|---|
| Manufacturer | National Semiconductor | Texas Instruments | Texas Instruments |
| Product Status | Obsolete | Active | Obsolete |
| Output Configuration | Positive | Positive | Positive |
| Output Type | Adjustable | Adjustable | Adjustable |
| Number of Regulators | 1 | 1 | 1 |
| Voltage - Input (Max) | 40V | 38V | 40V |
| Voltage - Output (Min/Fixed) | 1.2V | 1.2V | 1.2V |
| Voltage - Output (Max) | 37V | 32V | 37V |
| Voltage Dropout (Max) | - | - | - |
| Current - Output | 100mA | 100mA | 100mA |
| Current - Quiescent (Iq) | - | - | - |
| Current - Supply (Max) | - | - | - |
| PSRR | 80dB ~ 65dB (120Hz) | 80dB ~ 65dB (120Hz) | 80dB ~ 65dB (120Hz) |
| Control Features | - | - | - |
| Protection Features | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature, Short Circuit | Over Current, Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Through Hole | Surface Mount |
| Package / Case | 6-VFBGA | TO-226-3, TO-92-3 (TO-226AA) | 6-VFBGA |
| Supplier Device Package | 6-DSBGA | TO-92-3 | 6-DSBGA |
