Please send RFQ , we will respond immediately.
| Part Number | LF411CH | LF411CP | LF411CN | LF411CD |
|---|---|---|---|---|
| Manufacturer | National Semiconductor | Texas Instruments | Texas Instruments | Texas Instruments |
| Product Status | Active | Active | Obsolete | Active |
| Amplifier Type | J-FET | J-FET | J-FET | J-FET |
| Number of Circuits | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - |
| Slew Rate | 15V/µs | 13V/µs | 15V/µs | 13V/µs |
| Gain Bandwidth Product | 3 MHz | 3 MHz | 4 MHz | 3 MHz |
| -3db Bandwidth | - | - | - | - |
| Current - Input Bias | 50 pA | 50 pA | 50 pA | 50 pA |
| Voltage - Input Offset | 800 µV | 800 µV | 800 µV | 800 µV |
| Current - Supply | 2mA | 2mA | 1.8mA | 2mA |
| Current - Output / Channel | - | - | - | - |
| Voltage - Supply Span (Min) | 7 V | 7 V | 10 V | 7 V |
| Voltage - Supply Span (Max) | 36 V | 36 V | 36 V | 36 V |
| Operating Temperature | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C | 0°C ~ 70°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Surface Mount |
| Package / Case | TO-99-8 Metal Can | 8-DIP (0.300", 7.62mm) | 8-DIP (0.300", 7.62mm) | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | TO-99-8 | 8-PDIP | 8-PDIP | 8-SOIC |
