| Part Number | ISL6559CB-T | ISL6559CR-T | ISL6569CB-T | ISL6559CBZ-T | ISL6552CB-T | ISL6553CB-T | ISL6557CB-T | ISL6558CB-T |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Intersil | Intersil | Intersil | Renesas Electronics America Inc | Renesas Electronics America Inc | Intersil | Intersil | Intersil |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Active | Obsolete |
| Output Type | PWM Signal | PWM Signal | PWM Signal | PWM Signal | PWM Signal | PWM Signal | - | PWM Signal |
| Function | Step-Down | Step-Down | Step-Down | Step-Down | Step-Down | Step-Down | - | Step-Down |
| Output Configuration | Positive | Positive | Positive | Positive | Positive | Positive | - | Positive |
| Topology | Buck | Buck | Buck | Buck | Buck | Buck | - | Buck |
| Number of Outputs | 4 | 4 | 2 | 4 | 4 | 2 | - | 4 |
| Output Phases | 4 | 4 | 2 | 4 | 4 | 2 | - | 4 |
| Voltage - Supply (Vcc/Vdd) | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | - | 4.75V ~ 5.25V |
| Frequency - Switching | 80kHz ~ 1MHz | 80kHz ~ 1MHz | 80kHz ~ 1MHz | 80kHz ~ 1MHz | 50kHz ~ 1.5MHz | 50kHz ~ 1.5MHz | - | 80kHz ~ 1.5MHz |
| Duty Cycle (Max) | 75% | 75% | 75% | 75% | - | - | - | 75% |
| Synchronous Rectifier | - | - | - | - | - | - | - | - |
| Clock Sync | No | No | No | No | No | No | - | No |
| Serial Interfaces | - | - | - | - | - | - | - | - |
| Control Features | Current Limit, Enable, Frequency Control, Power Good | Current Limit, Enable, Frequency Control, Power Good | Current Limit, Enable, Frequency Control, Power Good | Current Limit, Enable, Frequency Control, Power Good | Enable, Frequency Control, Power Good | Enable, Frequency Control, Power Good | - | Enable, Frequency Control, Power Good |
| Operating Temperature | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | - | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | - | Surface Mount |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) | 32-VFQFN Exposed Pad | 24-SOIC (0.295", 7.50mm Width) | 28-SOIC (0.295", 7.50mm Width) | 20-SOIC (0.295", 7.50mm Width) | 16-SOIC (0.154", 3.90mm Width) | - | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 28-SOIC | 32-QFN (5x5) | 24-SOIC | 28-SOIC | 20-SOIC | 16-SOIC | - | 16-SOIC |
