| Part Number | FHP3131IL6X | FHP3131IS6X |
|---|---|---|
| Manufacturer | Fairchild Semiconductor | Fairchild Semiconductor |
| Product Status | Obsolete | Obsolete |
| Amplifier Type | Voltage Feedback | Voltage Feedback |
| Number of Circuits | 1 | 1 |
| Output Type | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 45V/µs | 45V/µs |
| Gain Bandwidth Product | - | - |
| -3db Bandwidth | 70 MHz | 70 MHz |
| Current - Input Bias | 1.4 µA | 1.4 µA |
| Voltage - Input Offset | 1 mV | 1 mV |
| Current - Supply | 400µA | 400µA |
| Current - Output / Channel | 35 mA | 35 mA |
| Voltage - Supply Span (Min) | 2.5 V | 2.5 V |
| Voltage - Supply Span (Max) | 12 V | 12 V |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 6-UFDFN | SOT-23-6 |
| Supplier Device Package | 6-MicroPak | SOT-23-6 |
