| Part Number | FDS7088N3 | FDS7098N3 | FDS7088SN3 | FDS7088N7 | FDS7288N3 | FDS7082N3 |
|---|---|---|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | Fairchild Semiconductor | Fairchild Semiconductor | Fairchild Semiconductor | onsemi | Fairchild Semiconductor |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| FET Type | N-Channel | N-Channel | N-Channel | N-Channel | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V | 30 V | 30 V | 30 V | 30 V | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 21A (Ta) | 14A (Ta) | 21A (Ta) | 23A (Ta) | 20A (Ta) | 17.5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 4mOhm @ 21A, 10V | 9mOhm @ 14A, 10V | 4mOhm @ 21A, 10V | 3mOhm @ 23A, 10V | 4.5mOhm @ 20.5A, 10V | 6mOhm @ 17.5A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 250µA | 3V @ 250µA | 3V @ 1mA | 3V @ 250µA | 3V @ 250µA | 3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 48 nC @ 5 V | 22 nC @ 5 V | 80 nC @ 10 V | 48 nC @ 5 V | 69 nC @ 10 V | 53 nC @ 10 V |
| Vgs (Max) | ±20V | ±20V | ±20V | ±20V | ±20V | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3845 pF @ 15 V | 1587 pF @ 15 V | 3230 pF @ 15 V | 3845 pF @ 15 V | 3300 pF @ 15 V | 2271 pF @ 15 V |
| FET Feature | - | - | - | - | - | - |
| Power Dissipation (Max) | 3W (Ta) | 3W (Ta) | 3W (Ta) | 3W (Ta) | 3W (Ta) | 3W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 8-SO | 8-SO | 8-SO | 8-SO | 8-SO | 8-SO |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) |
