| Part Number | FAN5365UC00X | FAN5365UC02X | FAN5355UC00X |
|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | Fairchild Semiconductor | Fairchild Semiconductor |
| Product Status | Obsolete | Obsolete | Active |
| Function | Step-Down | Step-Down | Step-Down |
| Output Configuration | Positive | Positive | Positive |
| Topology | Buck | Buck | Buck |
| Output Type | Programmable | Programmable | Programmable |
| Number of Outputs | 1 | 1 | 1 |
| Voltage - Input (Min) | 2.3V | 2.3V | 2.7V |
| Voltage - Input (Max) | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 0.75V | 0.75V | 0.75V |
| Voltage - Output (Max) | 1.44V | 1.44V | 1.54V |
| Current - Output | 800mA | 800mA | 800mA |
| Frequency - Switching | 6MHz | 6MHz | 3MHz |
| Synchronous Rectifier | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 9-UFBGA, WLCSP | 9-UFBGA, WLCSP | 12-UFBGA, WLCSP |
| Supplier Device Package | 9-WLCSP (1.22x1.22) | 9-WLCSP (1.22x1.22) | 12-WLCSP (2.23x1.46) |
