| Part Number | FAN4860UC33X | FAN48630UC33X | FAN4868UC33X |
|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | Fairchild Semiconductor | onsemi |
| Product Status | Not For New Designs | Active | Active |
| Function | Step-Up | Step-Up | Step-Up |
| Output Configuration | Positive | Positive | Positive |
| Topology | Boost | Boost | Boost |
| Output Type | Fixed | Programmable | Fixed |
| Number of Outputs | 1 | 1 | 1 |
| Voltage - Input (Min) | 2.3V | 2.35V | 2.3V |
| Voltage - Input (Max) | 3.2V | 5.5V | 3.2V |
| Voltage - Output (Min/Fixed) | 3.3V | 3.3V, 3.49V | 3.3V |
| Voltage - Output (Max) | - | - | - |
| Current - Output | 650mA (Switch) | 1.5A (Switch) | 300mA |
| Frequency - Switching | 3MHz | 2.5MHz | 3MHz |
| Synchronous Rectifier | Yes | Yes | Yes |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-UFBGA, WLCSP | 16-UFBGA, WLCSP | 6-XFBGA, WLCSP |
| Supplier Device Package | 6-WLCSP (1.23x0.88) | 16-WLCSP (1.78x1.78) | 6-WLCSP (0.88x1.23) |
