| Part Number | EL8300ISZ | EL8300IUZ | EL8302ISZ | EL8300IS |
|---|---|---|---|---|
| Manufacturer | Intersil | Intersil | Renesas Electronics America Inc | Elantec |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Amplifier Type | General Purpose | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 3 | 3 | 3 | 3 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 200V/µs | 200V/µs | 600V/µs | 200V/µs |
| Gain Bandwidth Product | 100 MHz | 100 MHz | 200 MHz | 100 MHz |
| -3db Bandwidth | 200 MHz | 200 MHz | 500 MHz | 200 MHz |
| Current - Input Bias | 1.4 µA | 1.4 µA | 6 µA | 1.4 µA |
| Voltage - Input Offset | 800 µV | 800 µV | 800 µV | 800 µV |
| Current - Supply | 2mA (x3 Channels) | 2mA (x3 Channels) | 5.6mA (x3 Channels) | 2mA (x3 Channels) |
| Current - Output / Channel | 65 mA | 65 mA | 65 mA | 65 mA |
| Voltage - Supply Span (Min) | 3 V | 3 V | 3 V | 3 V |
| Voltage - Supply Span (Max) | 5 V | 5 V | 5 V | 5 V |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) | 16-SSOP (0.154", 3.90mm Width) | 16-SOIC (0.154", 3.90mm Width) | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC | 16-QSOP | 16-SOIC | 16-SOIC |
