| Part Number | EL5166IW-T7A | EL5166IWZ-T7A | EL5167IW-T7A | EL5160IW-T7A | EL5161IW-T7A | EL5162IW-T7A | EL5163IW-T7A | EL5164IW-T7A | EL5165IW-T7A | EL5166IW-T7 |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Intersil | Renesas Electronics America Inc | Intersil | Elantec | Intersil | Renesas Electronics America Inc | Elantec | Elantec | Elantec | Elantec |
| Product Status | Obsolete | Active | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Amplifier Type | Current Feedback | Current Feedback | Current Feedback | Current Feedback | Current Feedback | Current Feedback | Current Feedback | Current Feedback | Current Feedback | Current Feedback |
| Number of Circuits | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Output Type | - | - | - | - | - | - | - | - | - | - |
| Slew Rate | 6000V/µs | 6000V/µs | 6000V/µs | 1700V/µs | 1700V/µs | 4000V/µs | 4000V/µs | 4700V/µs | 4700V/µs | 6000V/µs |
| Gain Bandwidth Product | - | - | - | - | - | - | - | - | - | - |
| -3db Bandwidth | 1.4 GHz | 1.4 GHz | 1.4 GHz | 200 MHz | 200 MHz | 500 MHz | 500 MHz | 600 MHz | 600 MHz | 1.4 GHz |
| Current - Input Bias | - | 8.5 µA | 8.5 µA | 5 µA | 5 µA | 2 µA | 2 µA | 2 µA | 2 µA | 8.5 µA |
| Voltage - Input Offset | 500 µV | 500 µV | 500 µV | 1.6 mV | 1.6 mV | 1.5 mV | 1.5 mV | 1.5 mV | 1.5 mV | 500 µV |
| Current - Supply | 8.5mA | 8.5mA | 8.5mA | 750µA | 750µA | 1.5mA | 1.5mA | 3.5mA | 3.5mA | 8.5mA |
| Current - Output / Channel | 200 mA | 200 mA | 200 mA | 140 mA | 140 mA | 100 mA | 100 mA | 190 mA | 140 mA | 200 mA |
| Voltage - Supply Span (Min) | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V |
| Voltage - Supply Span (Max) | 12 V | 12 V | 12 V | 10 V | 10 V | 12 V | 12 V | 12 V | 10 V | 12 V |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C (TA) | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOT-23-6 | SOT-23-6 | SC-74A, SOT-753 | SOT-23-6 | SC-74A, SOT-753 | SOT-23-6 | SC-74A, SOT-753 | SOT-23-6 | SC-74A, SOT-753 | SOT-23-6 |
| Supplier Device Package | SOT-23-6 | 6-SOT | SOT-23-5 | 6-SOT | SOT-23-5 | 6-SOT | SOT-23-5 | 6-SOT | SOT-23-5 | SOT-23-6 |
