| Part Number | DM7410N | DM7420N | DM7414N | DM7430N | DM7411N | DM7440N | DM7416N | DM7400N |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | National Semiconductor | Fairchild Semiconductor | National Semiconductor | National Semiconductor | Rochester Electronics, LLC | Rochester Electronics, LLC | onsemi | onsemi |
| Product Status | Active | Active | Active | Active | Active | Active | Obsolete | Obsolete |
| Logic Type | - | NAND Gate | Inverter | - | - | - | Inverter | NAND Gate |
| Number of Circuits | - | 2 | 6 | - | - | - | 6 | 4 |
| Number of Inputs | - | 4 | 1 | - | - | - | 1 | 2 |
| Features | - | - | Schmitt Trigger Input | - | - | - | Open Collector | - |
| Voltage - Supply | - | 4.75V ~ 5.25V | 4.75V ~ 5.25V | - | - | - | 4.75V ~ 5.25V | 4.75V ~ 5.25V |
| Current - Quiescent (Max) | - | 11 mA | 60 mA | - | - | - | - | - |
| Current - Output High, Low | - | 400µA, 16mA | 800µA, 16mA | - | - | - | -, 40mA | 400µA, 16mA |
| Logic Level - Low | - | 0.8V | 1.1V | - | - | - | 0.8V | 0.8V |
| Logic Level - High | - | 2V | 2V | - | - | - | 2V | 2V |
| Max Propagation Delay @ V, Max CL | - | 15ns @ 5V, 15pF | 22ns @ 5V, 15pF | - | - | - | 23ns @ 5V, 15pF | 22ns @ 5V, 15pF |
| Operating Temperature | - | 0°C ~ 70°C | 0°C ~ 70°C | - | - | - | 0°C ~ 70°C | 0°C ~ 70°C |
| Mounting Type | - | Through Hole | Through Hole | - | - | - | Through Hole | Through Hole |
| Supplier Device Package | - | 14-DIP | 14-PDIP | - | - | - | 14-MDIP | 14-MDIP |
| Package / Case | - | 14-DIP (0.300", 7.62mm) | 14-DIP (0.300", 7.62mm) | - | - | - | 14-DIP (0.300", 7.62mm) | 14-DIP (0.300", 7.62mm) |
