Please send RFQ , we will respond immediately.
| Part Number | BC858CMTF | BC859CMTF | BC858AMTF | BC858BMTF |
|---|---|---|---|---|
| Manufacturer | Fairchild Semiconductor | onsemi | Fairchild Semiconductor | Fairchild Semiconductor |
| Product Status | Active | Obsolete | Obsolete | Active |
| Transistor Type | PNP | PNP | PNP | PNP |
| Current - Collector (Ic) (Max) | 100 mA | 100 mA | 100 mA | 100 mA |
| Voltage - Collector Emitter Breakdown (Max) | 30 V | 30 V | 30 V | 30 V |
| Vce Saturation (Max) @ Ib, Ic | 650mV @ 5mA, 100mA | 650mV @ 5mA, 100mA | 650mV @ 5mA, 100mA | 650mV @ 5mA, 100mA |
| Current - Collector Cutoff (Max) | 15nA (ICBO) | 15nA (ICBO) | 15nA (ICBO) | 15nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 420 @ 2mA, 5V | 420 @ 2mA, 5V | 110 @ 2mA, 5V | 200 @ 2mA, 5V |
| Power - Max | 310 mW | 310 mW | 310 mW | 310 mW |
| Frequency - Transition | 150MHz | 150MHz | 150MHz | 150MHz |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 | SOT-23-3 | SOT-23-3 | SOT-23-3 |
