ADC0809CCV
  • Share:

National Semiconductor ADC0809CCV

Manufacturer No:
ADC0809CCV
Manufacturer:
National Semiconductor
Package:
Bulk
Datasheet:
ADC0809CCV Datasheet
ECAD Model:
-
Description:
IC ADC 8BIT SAR 28PLCC
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Number of Bits:8
Sampling Rate (Per Second):-
Number of Inputs:8
Input Type:Single Ended
Data Interface:Parallel
Configuration:MUX-S/H-ADC
Ratio - S/H:ADC:1:1
Number of A/D Converters:1
Architecture:SAR
Reference Type:External
Voltage - Supply, Analog:4.5V ~ 6V
Voltage - Supply, Digital:4.5V ~ 6V
Features:-
Operating Temperature:-40°C ~ 85°C
Package / Case:28-LCC (J-Lead)
Supplier Device Package:28-PLCC (11.51x11.51)
Mounting Type:Surface Mount
0 Remaining View Similar

In Stock

$2.96
199

Please send RFQ , we will respond immediately.

Similar Products

Part Number ADC0809CCV ADC0819CCV   ADC0809CCVX   ADC0808CCV   ADC0809CCN
Manufacturer National Semiconductor National Semiconductor Texas Instruments Texas Instruments Texas Instruments
Product Status Active Active Obsolete Obsolete Obsolete
Number of Bits 8 8 8 8 8
Sampling Rate (Per Second) - - 10k 10k 10k
Number of Inputs 8 - 8 8 8
Input Type Single Ended - Single Ended Single Ended Single Ended
Data Interface Parallel - Parallel Parallel Parallel
Configuration MUX-S/H-ADC - MUX-S/H-ADC MUX-S/H-ADC MUX-S/H-ADC
Ratio - S/H:ADC 1:1 - 1:1 1:1 1:1
Number of A/D Converters 1 1 1 1 1
Architecture SAR - SAR SAR SAR
Reference Type External - External External External
Voltage - Supply, Analog 4.5V ~ 6V - 4.5V ~ 6.5V 4.5V ~ 6.5V 4.5V ~ 6.5V
Voltage - Supply, Digital 4.5V ~ 6V - 4.5V ~ 6.5V 4.5V ~ 6.5V 4.5V ~ 6.5V
Features - - - - -
Operating Temperature -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C
Package / Case 28-LCC (J-Lead) 28-LCC (J-Lead) 28-LCC (J-Lead) 28-LCC (J-Lead) 28-DIP (0.600", 15.24mm)
Supplier Device Package 28-PLCC (11.51x11.51) 28-PLCC (11.43x11.43) 28-PLCC (11.51x11.51) 28-PLCC (11.51x11.51) 28-DIP
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Through Hole
