Fairchild Semiconductor-74LVTH32374GX - Logic - Flip Flops Product Specifications and Latest Quotes

Function:	Standard
Type:	D-Type
Output Type:	Tri-State, Non-Inverted
Number of Elements:	4
Number of Bits per Element:	8
Clock Frequency:	160 MHz
Max Propagation Delay @ V, Max CL:	4.5ns @ 3.3V, 50pF
Trigger Type:	Positive Edge
Current - Output High, Low:	32mA, 64mA
Voltage - Supply:	2.7V ~ 3.6V
Current - Quiescent (Iq):	190 µA
Input Capacitance:	4 pF
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	96-FBGA (13.5x5.5)
Package / Case:	96-LFBGA

Fairchild Semiconductor 74LVTH32374GX
