| Part Number | MAZ43600MF | MAZ43900MF | MAZ41600MF | MAZ43000MF | MAZ43300MF |
|---|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Voltage - Zener (Nom) (Vz) | 36 V | 39 V | 16 V | 30 V | 33 V |
| Tolerance | ±6% | ±5% | ±6% | ±7% | ±6% |
| Power - Max | 370 mW | 370 mW | 370 mW | 370 mW | 370 mW |
| Impedance (Max) (Zzt) | 90 Ohms | 130 Ohms | 40 Ohms | 80 Ohms | 80 Ohms |
| Current - Reverse Leakage @ Vr | 50 nA @ 25 V | 50 nA @ 27 V | 50 nA @ 11 V | 50 nA @ 21 V | 50 nA @ 23 V |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA | 900 mV @ 10 mA |
| Operating Temperature | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial |
| Supplier Device Package | DO34-A2 | DO34-A2 | DO34-A2 | DO34-A2 | DO34-A2 |
