| Part Number | LNJ808R8ERA | LNJ808R83RA | LNJ808R88RA |
|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Obsolete |
| Color | Orange | Orange | Orange |
| Configuration | Standard | Standard | Standard |
| Lens Color | - | - | Red |
| Lens Transparency | - | - | Diffused |
| Millicandela Rating | 1.1mcd | 32mcd | 6.5mcd |
| Lens Style | Rectangle with Flat Top | Rectangle with Flat Top | Rectangle with Flat Top |
| Lens Size | 0.90mm x 0.80mm | 0.90mm x 0.80mm | 0.90mm x 0.80mm |
| Voltage - Forward (Vf) (Typ) | 1.8V | 2.03V | 1.9V |
| Current - Test | 5mA | 10mA | 10mA |
| Viewing Angle | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Wavelength - Dominant | - | - | - |
| Wavelength - Peak | 630nm | 630nm | 620nm |
| Features | - | - | - |
| Package / Case | 0603 (1608 Metric) | 0603 (1608 Metric) | 0603 (1608 Metric) |
| Supplier Device Package | - | - | SS Type LED |
| Size / Dimension | 1.60mm L x 0.80mm W | 1.60mm L x 0.80mm W | 1.60mm L x 0.80mm W |
| Height (Max) | 0.90mm | 0.90mm | 0.90mm |
