Please send RFQ , we will respond immediately.
| Part Number | LN29RPP | LN89RPP | LN29RPX | LN29RCP |
|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Color | Red | Orange | Red | Red |
| Configuration | Standard | Standard | Standard | Standard |
| Lens Color | Red | Red | Red | Red |
| Lens Transparency | Diffused | Diffused | Diffused | Clear |
| Millicandela Rating | 1.5mcd | 10mcd | 2mcd | 3.5mcd |
| Lens Style | Round with Domed Top | Round with Domed Top | Round with Domed Top | Round with Domed Top |
| Lens Size | 4.00mm Dia | 4.00mm Dia | 4.00mm Dia | 4.00mm Dia |
| Voltage - Forward (Vf) (Typ) | 2.2V | 2.1V | 2.2V | 2.2V |
| Current - Test | 15mA | 20mA | 15mA | 15mA |
| Viewing Angle | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Wavelength - Dominant | - | - | - | - |
| Wavelength - Peak | 700nm | 630nm | 700nm | 700nm |
| Features | - | - | - | - |
| Package / Case | Radial | Radial | Radial | Radial |
| Supplier Device Package | 4mm Round | 4mm Round | 4mm Round | 4mm Round |
| Size / Dimension | - | - | - | - |
| Height (Max) | 6.20mm | 6.20mm | 6.20mm | 6.20mm |
