| Part Number | EZP-Q38805LTC | EZP-Q38805LTD |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Active | Active |
| Capacitance | 8 µF | 8 µF |
| Tolerance | ±5% | ±5% |
| Voltage Rating - AC | 380V | 380V |
| Voltage Rating - DC | - | - |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 6 mOhms | 11.9 mOhms |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 105°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial | Radial |
| Size / Dimension | 1.634" L x 1.043" W (41.50mm x 26.50mm) | 1.634" L x 1.083" W (41.50mm x 27.50mm) |
| Height - Seated (Max) | 1.654" (42.00mm) | 1.693" (43.00mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 1.476" (37.50mm) | 1.476" (37.50mm) |
| Applications | General Purpose | General Purpose |
| Ratings | - | - |
| Features | Long Life, Low ESR | Long Life, Low ESR |
