| Part Number | EZP-Q38156MTC | EZP-Q38156MTB |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Active | Active |
| Capacitance | 15 µF | 15 µF |
| Tolerance | ±5% | ±5% |
| Voltage Rating - AC | 380V | 380V |
| Voltage Rating - DC | - | - |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 9.3 mOhms | 7.1 mOhms |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 105°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial - 4 Leads | Radial |
| Size / Dimension | 2.264" L x 1.181" W (57.50mm x 30.00mm) | 1.673" L x 1.496" W (42.50mm x 38.00mm) |
| Height - Seated (Max) | 2.028" (51.50mm) | 2.283" (58.00mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 2.067" (52.50mm) | 1.476" (37.50mm) |
| Applications | General Purpose | General Purpose |
| Ratings | - | - |
| Features | Long Life, Low ESR | Long Life, Low ESR |
