| Part Number | EZP-Q33685LTA | EZP-Q33605LTA |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Active | Active |
| Capacitance | 6.8 µF | 6 µF |
| Tolerance | ±5% | ±5% |
| Voltage Rating - AC | 330V | 330V |
| Voltage Rating - DC | - | - |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 12.6 mOhms | 13.5 mOhms |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 105°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial | Radial |
| Size / Dimension | 1.614" L x 1.024" W (41.00mm x 26.00mm) | 1.614" L x 0.866" W (41.00mm x 22.00mm) |
| Height - Seated (Max) | 1.614" (41.00mm) | 1.437" (36.50mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 1.476" (37.50mm) | 1.476" (37.50mm) |
| Applications | General Purpose | General Purpose |
| Ratings | - | - |
| Features | Long Life, Low ESR | Long Life, Low ESR |
