| Part Number | ENW-89823C2JF | ENW-89823C2KF | ENW-89827C2JF | ENW-89829C2JF | ENW-89823A2JF |
|---|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Not For New Designs | Obsolete | Obsolete | Obsolete |
| RF Family/Standard | Bluetooth | Bluetooth | Bluetooth | Bluetooth | Bluetooth |
| Protocol | Bluetooth v4.0 | Bluetooth v4.0 | Bluetooth v4.0 | Bluetooth v2.1 +EDR | Bluetooth v4.0 |
| Modulation | GFSK | GFSK | GFSK | GFSK | GFSK |
| Frequency | 2.4GHz | 2.4GHz | 2.4GHz | 2.4GHz | 2.4GHz |
| Data Rate | 3Mbps | 3Mbps | 3Mbps | 3Mbps | 3Mbps |
| Power - Output | 10dBm | 10dBm | 10dBm | 10.5dBm | 10dBm |
| Sensitivity | -93dBm | -93dBm | -93dBm | -93dBm | -93dBm |
| Serial Interfaces | I²S, UART | I²S, UART | I²S, UART | I²S, UART | I²S, UART |
| Antenna Type | Antenna Not Included | Antenna Not Included | Antenna Not Included | Antenna Not Included | Integrated, Chip |
| Utilized IC / Part | CC2564 | CC2564 | CC2567 | Si1000 | ESP32 |
| Memory Size | - | - | - | - | - |
| Voltage - Supply | 1.7V ~ 4.8V | 1.7V ~ 4.8V | 1.7V ~ 4.8V | 1.7V ~ 4.8V | 1.7V ~ 4.8V |
| Current - Receiving | 33mA | 33mA | 33mA | 40mA | 33mA |
| Current - Transmitting | 33mA | 33mA | 33mA | 40mA | 33mA |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -20°C ~ 70°C | -40°C ~ 85°C | -20°C ~ 70°C | -20°C ~ 70°C | -20°C ~ 70°C |
| Package / Case | Module | Module | PCB Module | Module | Module |
