ELL-4GG1R8N
  • Share:

Panasonic Electronic Components ELL-4GG1R8N

Manufacturer No:
ELL-4GG1R8N
Manufacturer:
Panasonic Electronic Components
Package:
Tape & Reel (TR)
Datasheet:
ELL-4GG1R8N Datasheet
ECAD Model:
-
Description:
FIXED IND 1.8UH 1.55A 71MOHM SMD
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Wirewound
Material - Core:-
Inductance:1.8 µH
Tolerance:±30%
Current Rating (Amps):1.55 A
Current - Saturation (Isat):1.9A
Shielding:Shielded
DC Resistance (DCR):71mOhm
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:-
Operating Temperature:-
Inductance Frequency - Test:100 kHz
Features:-
Mounting Type:Surface Mount
Package / Case:Nonstandard
Supplier Device Package:-
Size / Dimension:0.150" L x 0.150" W (3.80mm x 3.80mm)
Height - Seated (Max):0.055" (1.40mm)
0 Remaining View Similar

In Stock

$0.59
1,322

Please send RFQ , we will respond immediately.

Similar Products

Part Number ELL-4GG1R8N ELL-4GG6R8N   ELL-4GG1R2N
Manufacturer Panasonic Electronic Components Panasonic Electronic Components Panasonic Electronic Components
Product Status Obsolete Obsolete Obsolete
Type Wirewound Wirewound Wirewound
Material - Core - - -
Inductance 1.8 µH 6.8 µH 1.2 µH
Tolerance ±30% ±30% ±30%
Current Rating (Amps) 1.55 A 930 mA 1.9 A
Current - Saturation (Isat) 1.9A 1.05A 2.4A
Shielding Shielded Shielded Shielded
DC Resistance (DCR) 71mOhm 200mOhm 50mOhm
Q @ Freq - - -
Frequency - Self Resonant - - -
Ratings - - -
Operating Temperature - - -
Inductance Frequency - Test 100 kHz 100 kHz 100 kHz
Features - - -
Mounting Type Surface Mount Surface Mount Surface Mount
Package / Case Nonstandard Nonstandard Nonstandard
Supplier Device Package - - -
Size / Dimension 0.150" L x 0.150" W (3.80mm x 3.80mm) 0.150" L x 0.150" W (3.80mm x 3.80mm) 0.150" L x 0.150" W (3.80mm x 3.80mm)
Height - Seated (Max) 0.055" (1.40mm) 0.055" (1.40mm) 0.055" (1.40mm)
