| Part Number | ELJ-RG15NJF | ELJ-RF15NJF |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete |
| Type | - | Multilayer |
| Material - Core | Non-Magnetic | Non-Magnetic |
| Inductance | 15 nH | 15 nH |
| Tolerance | ±5% | ±5% |
| Current Rating (Amps) | 150 mA | 240 mA |
| Current - Saturation (Isat) | - | - |
| Shielding | Unshielded | Unshielded |
| DC Resistance (DCR) | 2.2Ohm Max | 600mOhm Max |
| Q @ Freq | 3 @ 100MHz | 8 @ 100MHz |
| Frequency - Self Resonant | 5.6GHz | 2.5GHz |
| Ratings | - | - |
| Operating Temperature | - | -20°C ~ 85°C |
| Inductance Frequency - Test | 100 MHz | 100 MHz |
| Features | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 0201 (0603 Metric) | 0402 (1005 Metric) |
| Supplier Device Package | 0201 (0603 Metric) | 0402 (1005 Metric) |
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| Height - Seated (Max) | 0.012" (0.31mm) | 0.022" (0.55mm) |
