ELC-18E8R2L
  • Share:

Panasonic Electronic Components ELC-18E8R2L

Manufacturer No:
ELC-18E8R2L
Manufacturer:
Panasonic Electronic Components
Package:
Bulk
Datasheet:
ELC-18E8R2L Datasheet
ECAD Model:
-
Description:
FIXED IND 8.2UH 6.2A 13 MOHM TH
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Type:Drum Core, Wirewound
Material - Core:Ferrite
Inductance:8.2 µH
Tolerance:±20%
Current Rating (Amps):6.2 A
Current - Saturation (Isat):-
Shielding:Shielded
DC Resistance (DCR):13mOhm
Q @ Freq:-
Frequency - Self Resonant:-
Ratings:-
Operating Temperature:-
Inductance Frequency - Test:10 kHz
Features:-
Mounting Type:Through Hole
Package / Case:Radial, Vertical Cylinder
Supplier Device Package:-
Size / Dimension:0.748" Dia (19.00mm)
Height - Seated (Max):0.988" (25.10mm)
0 Remaining View Similar

In Stock

-
596

Please send RFQ , we will respond immediately.

Similar Products

Part Number ELC-18E8R2L ELC-18B8R2L   ELC-18E822L   ELC-18E8R2
Manufacturer Panasonic Electronic Components Panasonic Electronic Components Panasonic Electronic Components Panasonic Electronic Components
Product Status Obsolete Obsolete Obsolete Active
Type Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound Drum Core, Wirewound
Material - Core Ferrite Ferrite Ferrite Ferrite
Inductance 8.2 µH 8.2 µH 8.2 mH 8.2 µH
Tolerance ±20% ±20% ±10% ±20%
Current Rating (Amps) 6.2 A 6.6 A 350 mA 6.2 A
Current - Saturation (Isat) - - - -
Shielding Shielded Unshielded Shielded Shielded
DC Resistance (DCR) 13mOhm 16mOhm 2.4Ohm 13mOhm
Q @ Freq - - - -
Frequency - Self Resonant - - - -
Ratings - - - -
Operating Temperature - - - -
Inductance Frequency - Test 10 kHz 10 kHz 10 kHz 10 kHz
Features - - - -
Mounting Type Through Hole Through Hole Through Hole Through Hole
Package / Case Radial, Vertical Cylinder Radial, Vertical Cylinder (Open) Radial, Vertical Cylinder Radial, Vertical Cylinder (Open)
Supplier Device Package - - - -
Size / Dimension 0.748" Dia (19.00mm) 0.787" Dia (20.00mm) 0.748" Dia (19.00mm) 0.748" Dia (19.00mm)
Height - Seated (Max) 0.988" (25.10mm) 1.063" (27.00mm) 0.988" (25.10mm) 0.984" (25.00mm)
