| Part Number | ELC-18E5R6L | ELC-18B5R6L | ELC-18E5R6 |
|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite | Ferrite |
| Inductance | 5.6 µH | 5.6 µH | 5.6 µH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 6.7 A | 7.4 A | 6.7 A |
| Current - Saturation (Isat) | - | - | - |
| Shielding | Shielded | Unshielded | Shielded |
| DC Resistance (DCR) | 11mOhm | 13mOhm | 11mOhm |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | - | - | - |
| Ratings | - | - | - |
| Operating Temperature | - | - | - |
| Inductance Frequency - Test | 10 kHz | 10 kHz | 10 kHz |
| Features | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial, Vertical Cylinder | Radial, Vertical Cylinder (Open) | Radial, Vertical Cylinder (Open) |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.748" Dia (19.00mm) | 0.787" Dia (20.00mm) | 0.748" Dia (19.00mm) |
| Height - Seated (Max) | 0.988" (25.10mm) | 1.063" (27.00mm) | 0.984" (25.00mm) |
