| Part Number | ELC-18E391L | ELC-18B391L | ELC-18E331L | ELC-18E390L | ELC-18E391 |
|---|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Active |
| Type | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound | Drum Core, Wirewound |
| Material - Core | Ferrite | Ferrite | Ferrite | Ferrite | Ferrite |
| Inductance | 390 µH | 390 µH | 330 µH | 39 µH | 390 µH |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% |
| Current Rating (Amps) | 1.8 A | 1.8 A | 1.9 A | 4.5 A | 1.8 A |
| Current - Saturation (Isat) | - | - | - | - | - |
| Shielding | Shielded | Unshielded | Shielded | Shielded | Shielded |
| DC Resistance (DCR) | 120mOhm | 150mOhm | 110mOhm | 28mOhm | 120mOhm |
| Q @ Freq | - | - | - | - | - |
| Frequency - Self Resonant | - | - | - | - | - |
| Ratings | - | - | - | - | - |
| Operating Temperature | - | - | - | - | - |
| Inductance Frequency - Test | 10 kHz | 10 kHz | 10 kHz | 10 kHz | 10 kHz |
| Features | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial, Vertical Cylinder | Radial, Vertical Cylinder (Open) | Radial, Vertical Cylinder | Radial, Vertical Cylinder | Radial, Vertical Cylinder (Open) |
| Supplier Device Package | - | - | - | - | - |
| Size / Dimension | 0.748" Dia (19.00mm) | 0.787" Dia (20.00mm) | 0.748" Dia (19.00mm) | 0.748" Dia (19.00mm) | 0.748" Dia (19.00mm) |
| Height - Seated (Max) | 0.988" (25.10mm) | 1.063" (27.00mm) | 0.988" (25.10mm) | 0.988" (25.10mm) | 0.984" (25.00mm) |
