EHF-FD1812D
  • Share:

Panasonic Electronic Components EHF-FD1812D

Manufacturer No:
EHF-FD1812D
Manufacturer:
Panasonic Electronic Components
Package:
Tape & Reel (TR)
Datasheet:
EHF-FD1812D Datasheet
ECAD Model:
-
Description:
RF DIR COUPLER 880-915MHZ 0805
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Coupler Type:Dual Band, Dual Path
Frequency:880MHz ~ 915MHz, 1.71GHz ~ 1.785GHz
Coupling Factor:19dB, 14dB
Applications:Cellular
Insertion Loss:0.35dB, 0.45dB
Power - Max:3.2W, 1.5W
Isolation:24dB, 17dB
Return Loss:-
Package / Case:0805 (2012 Metric)
Supplier Device Package:0805 (2012 Metric)
0 Remaining View Similar

In Stock

-
76

Please send RFQ , we will respond immediately.
