| Part Number | EEC-EP0F333Y | EEC-EP0E333Y | EEC-EP0F303Y | EEC-EP0F333A |
|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Capacitance | 33 mF | 33 mF | 30 mF | 33 mF |
| Tolerance | -20%, +80% | -20%, +80% | -20%, +80% | -20%, +80% |
| Voltage - Rated | 3.3 V | 2.6 V | 3.3 V | 3.3 V |
| ESR (Equivalent Series Resistance) | 350Ohm @ 1kHz | 350Ohm @ 1kHz | 350Ohm @ 1kHz | 350Ohm @ 1kHz |
| Lifetime @ Temp. | 250 Hrs @ 60°C | 500 Hrs @ 60°C | 250 Hrs @ 60°C | 250 Hrs @ 60°C |
| Termination | SMD (SMT) Tabs | SMD (SMT) Tabs | SMD (SMT) Tabs | SMD (SMT) Tabs |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Coin, Wide and Thin Terminals - Opposite Sides | Coin, Wide and Thin Terminals - Opposite Sides | Coin, Wide and Thin Terminals - Opposite Sides | Coin, Wide and Thin Terminals - Opposite Sides |
| Lead Spacing | - | - | - | - |
| Size / Dimension | 0.150" Dia (3.80mm) | 0.150" Dia (3.80mm) | 0.150" Dia (3.80mm) | 0.150" Dia (3.80mm) |
| Height - Seated (Max) | 0.061" (1.55mm) | 0.061" (1.55mm) | 0.039" (1.00mm) | 0.059" (1.50mm) |
| Operating Temperature | -10°C ~ 60°C | -10°C ~ 60°C | -10°C ~ 60°C | -10°C ~ 60°C |
