| Part Number | ECW-F4334JB | ECW-F4394JB | ECW-F4334JL |
|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Active | Active | Active |
| Capacitance | 0.33 µF | 0.39 µF | 0.33 µF |
| Tolerance | ±5% | ±5% | ±5% |
| Voltage Rating - AC | 200V | 200V | 141V |
| Voltage Rating - DC | 400V | 400V | 400V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | - | - | - |
| Operating Temperature | -25°C ~ 85°C | -25°C ~ 85°C | -40°C ~ 105°C |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial |
| Size / Dimension | 0.787" L x 0.453" W (20.00mm x 11.50mm) | 0.906" L x 0.531" W (23.00mm x 13.50mm) | 0.709" L x 0.378" W (18.00mm x 9.60mm) |
| Height - Seated (Max) | 0.768" (19.50mm) | 0.866" (22.00mm) | 0.622" (15.80mm) |
| Termination | PC Pins | PC Pins | PC Pins |
| Lead Spacing | 0.669" (17.00mm) | 0.787" (20.00mm) | 0.591" (15.00mm) |
| Applications | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching |
| Ratings | - | - | - |
| Features | - | - | - |
