| Part Number | ECW-F2W225KA | ECW-F2W225JA |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Active | Active |
| Capacitance | 2.2 µF | 2.2 µF |
| Tolerance | ±10% | ±5% |
| Voltage Rating - AC | - | 84V |
| Voltage Rating - DC | 450V | 450V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | - | - |
| Operating Temperature | -40°C ~ 105°C | -40°C ~ 105°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial | Radial |
| Size / Dimension | 0.740" L x 0.504" W (18.80mm x 12.80mm) | 0.740" L x 0.504" W (18.80mm x 12.80mm) |
| Height - Seated (Max) | 0.764" (19.40mm) | 0.764" (19.40mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 0.591" (15.00mm) | 0.591" (15.00mm) |
| Applications | High Frequency, Switching | High Frequency, Switching |
| Ratings | - | - |
| Features | - | - |
