| Part Number | DZ2405600L | DZ2J05600L | DZ2705600L | DZ2405100L |
|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Voltage - Zener (Nom) (Vz) | 5.6 V | 5.6 V | 5.6 V | 5.1 V |
| Tolerance | ±5% | ±5% | ±5% | ±5% |
| Power - Max | 2 W | 200 mW | 120 mW | 2 W |
| Impedance (Max) (Zzt) | 40 Ohms | 40 Ohms | 40 Ohms | 50 Ohms |
| Current - Reverse Leakage @ Vr | 20 µA @ 2 V | 500 nA @ 2.5 V | 500 nA @ 2.5 V | 20 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 200 mA | 1 V @ 10 mA | 1 V @ 10 mA | 1.2 V @ 200 mA |
| Operating Temperature | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOD-128 | SC-90, SOD-323F | 2-SMD, Flat Lead | SOD-128 |
| Supplier Device Package | TMiniP2-F2-B | SMini2-F5-B | SSSMini2-F4-B | TMiniP2-F2-B |
