| Part Number | DSC5G0200L | DSC9G0200L |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Transistor Type | NPN | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 20V | 20V |
| Frequency - Transition | 650MHz | 650MHz |
| Noise Figure (dB Typ @ f) | 3.3dB @ 100MHz | 3.3dB @ 100MHz |
| Gain | 24dB | 24dB |
| Power - Max | 150mW | 125mW |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 65 @ 1mA, 6V | 65 @ 1mA, 6V |
| Current - Collector (Ic) (Max) | 15mA | 15mA |
| Operating Temperature | 150°C (TJ) | 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | SC-85 | SC-89, SOT-490 |
| Supplier Device Package | SMini3-F2-B | SSMini3-F3-B |
