| Part Number | DB3J407K0L | DB3X407K0L |
|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Diode Type | Schottky | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 40 V | 40 V |
| Current - Average Rectified (Io) | 500mA | 500mA |
| Voltage - Forward (Vf) (Max) @ If | 550 mV @ 500 mA | 550 mV @ 500 mA |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 5 ns | 3.6 ns |
| Current - Reverse Leakage @ Vr | 100 µA @ 35 V | 100 µA @ 35 V |
| Capacitance @ Vr, F | 12pF @ 10V, 1MHz | 10.5pF @ 10V, 1MHz |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | SC-85 | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SMini3-F2-B | MINI3-G3-B |
| Operating Temperature - Junction | 125°C (Max) | 125°C (Max) |
