| Part Number | AN17822A | AN17823A | AN17827A | AN17832A | AN17821A |
|---|---|---|---|---|---|
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Type | Class AB | Class AB | Class AB | Class AB | Class AB |
| Output Type | 2-Channel (Stereo) | 1-Channel (Mono) | 1-Channel (Mono) | 3-Channel | 2-Channel (Stereo) |
| Max Output Power x Channels @ Load | 5W x 2 @ 8Ohm | 4 W x 1 | 2.5W x 1 @ 8Ohm | 30W x 1 @ 8Ohm; 15W x 2 @ 4Ohm | 5W x 2 @ 8Ohm |
| Voltage - Supply | 3.5V ~ 15V | 3.5V ~ 13.5V | 6V ~ 14.5V | ±5V ~ 15V | 3.5V ~ 13.5V |
| Features | Standby, Thermal Protection, Volume Control | Standby, Volume Control | Thermal Shutdown Protection | Mute, Standby, Thermal Protection | Standby, Volume Control |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Operating Temperature | -25°C ~ 70°C (TA) | 25°C ~ 70°C (TA) | -20°C ~ 75°C (TA) | - | -25°C ~ 70°C (TA) |
| Supplier Device Package | 12-SIL | 9-HSIP | 16-DIP | 12-SIL | 12-SIL |
| Package / Case | 12-SIP + Tab | 9-SIP | 16-DIP (0.300", 7.62mm) | 12-SIP + Tab | 12-SIP + Tab |
