Please send RFQ , we will respond immediately.
| Part Number | UC3843AD2 | UC3843ADX | UC3843AD8 | UC3843AN2 | UC3843ADR2 | UC3843ADM | UC3843AD | UC3843AD1 |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | onsemi | Fairchild Semiconductor | Texas Instruments | onsemi | onsemi | Microsemi Corporation | Texas Instruments | STMicroelectronics |
| Product Status | Active | Active | Active | Active | Obsolete | Discontinued at Digi-Key | Active | Obsolete |
| Output Type | Transistor Driver | - | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver | Transistor Driver |
| Function | Step-Up, Step-Up/Step-Down | - | Step-Up, Step-Down, Step-Up/Step-Down | Step-Up, Step-Up/Step-Down | Step-Up, Step-Up/Step-Down | Step-Up, Step-Down | Step-Up, Step-Down, Step-Up/Step-Down | Step-Up, Step-Up/Step-Down |
| Output Configuration | Positive, Isolation Capable | - | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable | Positive, Isolation Capable |
| Topology | Boost, Buck, Flyback, Forward | - | Boost, Buck, Flyback, Forward | Boost, Buck, Flyback, Forward | Boost, Flyback | Boost, Buck, Flyback, Forward | Boost, Buck, Flyback, Forward | Boost, Flyback |
| Number of Outputs | 1 | - | 1 | 1 | 1 | 1 | 1 | 1 |
| Output Phases | 1 | - | 1 | 1 | 1 | 1 | 1 | 1 |
| Voltage - Supply (Vcc/Vdd) | 7.6V ~ 30V | - | 7.6V ~ 30V | 7.6V ~ 30V | 7.6V ~ 30V | 7.6V ~ 30V | 7.6V ~ 30V | 10V ~ 30V |
| Frequency - Switching | Up to 500kHz | - | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz | Up to 500kHz |
| Duty Cycle (Max) | 96% | - | 96% | 96% | 96% | 96% | 96% | 96% |
| Synchronous Rectifier | No | - | No | No | No | No | No | No |
| Clock Sync | No | - | No | No | No | No | No | No |
| Serial Interfaces | - | - | - | - | - | - | - | - |
| Control Features | Frequency Control | - | Frequency Control | Frequency Control | Frequency Control | Frequency Control | Frequency Control | Frequency Control |
| Operating Temperature | -40°C ~ 150°C (TJ) | - | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount | - | Surface Mount | Through Hole | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | - | 8-SOIC (0.154", 3.90mm Width) | 8-DIP (0.300", 7.62mm) | 14-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) | 14-SOIC (0.154", 3.90mm Width) | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC | - | 8-SOIC | 8-PDIP | 14-SOIC | 8-SOIC | 14-SOIC | 8-SOIC |
