| Part Number | SA7V5A | SA8V5A | SA7V5CA | SA75A | SA7V0A |
|---|---|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi | Littelfuse Inc. | onsemi |
| Product Status | Obsolete | Obsolete | Obsolete | Active | Obsolete |
| Type | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | - | 1 | 1 |
| Bidirectional Channels | - | - | 1 | - | - |
| Voltage - Reverse Standoff (Typ) | 7.5V | 8.5V | 7.5V | 75V | 7V |
| Voltage - Breakdown (Min) | 8.33V | 9.44V | 8.33V | 83.3V | 7.78V |
| Voltage - Clamping (Max) @ Ipp | 12.9V | 14.4V | 12.9V | 121V | 12V |
| Current - Peak Pulse (10/1000µs) | 38.8A | 34.7A | 38.8A | 4.2A | 41.7A |
| Power - Peak Pulse | 500W | 500W | 500W | 500W | 500W |
| Power Line Protection | No | No | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | - | - | - | - |
| Operating Temperature | - | - | - | -55°C ~ 175°C (TJ) | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AC, DO-15, Axial | DO-204AC, DO-15, Axial | DO-204AC, DO-15, Axial | DO-204AC, DO-15, Axial | DO-204AC, DO-15, Axial |
| Supplier Device Package | DO-15 | DO-15 | DO-15 | DO-204AC (DO-15) | DO-15 |
