Please send RFQ , we will respond immediately.
| Part Number | P6KE62ARL | P6KE68ARL | P6KE62ARLG |
|---|---|---|---|
| Manufacturer | onsemi | STMicroelectronics | onsemi |
| Product Status | Obsolete | Obsolete | Not For New Designs |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | 1 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 53V | 58V | 53V |
| Voltage - Breakdown (Min) | 58.9V | 64.6V | 58.9V |
| Voltage - Clamping (Max) @ Ipp | 85V | 121V | 85V |
| Current - Peak Pulse (10/1000µs) | 7.1A (8/20µs) | 33A (8/20µs) | 7.1A (8/20µs) |
| Power - Peak Pulse | 600W | 600W | 600W |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | - | 625pF @ 1MHz | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | - | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | T-18, Axial | DO-204AC, DO-15, Axial | T-18, Axial |
| Supplier Device Package | Axial | DO-15 (DO-204AC) | Axial |
