| Part Number | NZL6V8AXV3T1 | NZL6V8AXV3T1G | NZL6V2AXV3T1 |
|---|---|---|---|
| Manufacturer | onsemi | onsemi | onsemi |
| Product Status | Obsolete | Active | Obsolete |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 2 | 2 | 2 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 4.5V | 4.5V | - |
| Voltage - Breakdown (Min) | 6.46V | 6.46V | - |
| Voltage - Clamping (Max) @ Ipp | 7.9V | 7.9V | - |
| Current - Peak Pulse (10/1000µs) | 11.9A (8/20µs) | 11.9A (8/20µs) | - |
| Power - Peak Pulse | 73W | 73W | - |
| Power Line Protection | No | No | No |
| Applications | General Purpose | Automotive | General Purpose |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SC-89, SOT-490 | SC-89, SOT-490 | SC-89, SOT-490 |
| Supplier Device Package | SC-89-3 | SC-89-3 | SC-89-3 |
