| Part Number | NTK3043NT1H | NTK3043NT1G |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Active | Active |
| FET Type | - | N-Channel |
| Technology | - | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | - | 20 V |
| Current - Continuous Drain (Id) @ 25°C | - | 210mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 1.65V, 4.5V |
| Rds On (Max) @ Id, Vgs | - | 3.4Ohm @ 10mA, 4.5V |
| Vgs(th) (Max) @ Id | - | 1.3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | - | - |
| Vgs (Max) | - | ±10V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 11 pF @ 10 V |
| FET Feature | - | - |
| Power Dissipation (Max) | - | 310mW (Ta) |
| Operating Temperature | - | -55°C ~ 150°C (TJ) |
| Mounting Type | - | Surface Mount |
| Supplier Device Package | - | SOT-723 |
| Package / Case | - | SOT-723 |
