Please send RFQ , we will respond immediately.
| Part Number | NLAST9431MTR2G | NLAS9431MTR2G |
|---|---|---|
| Manufacturer | onsemi | onsemi |
| Product Status | Obsolete | Obsolete |
| Switch Circuit | DPDT | DPDT |
| Multiplexer/Demultiplexer Circuit | 2:2 | 2:2 |
| Number of Circuits | 1 | 2 |
| On-State Resistance (Max) | 25Ohm | 25Ohm |
| Channel-to-Channel Matching (ΔRon) | 2Ohm | - |
| Voltage - Supply, Single (V+) | 2V ~ 5.5V | 2V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - | - |
| Switch Time (Ton, Toff) (Max) | 14ns, 8ns | 14ns, 5ns |
| -3db Bandwidth | 200MHz | 175MHz |
| Charge Injection | 3pC | 3pC |
| Channel Capacitance (CS(off), CD(off)) | 10pF, 10pF | 10pF, 10pF |
| Current - Leakage (IS(off)) (Max) | 1nA | 10µA |
| Crosstalk | - | -98dB @ 100kHz |
| Operating Temperature | -55°C ~ 125°C (TA) | -55°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 16-WFQFN | 16-WFQFN |
| Supplier Device Package | 16-WQFN (1.8x2.6) | 16-WQFN (1.8x2.6) |
